MakerChat 0x0E - Introduction to Node-RED 🔧

MakerChat

264

MakerGram last edited by

This month, we're discussing Node-RED

Node-RED is a programming tool for wiring together hardware devices, APIs and online services in new and interesting ways.

It provides a browser-based editor that makes it easy to wire together flows using the wide range of nodes in the palette that can be deployed to its runtime in a single click.

In this MakerChat 0x0E we are going to learn and experiment with Node-RED using raspberry pi. We will be installing, and creating flows, nodes and GUI using Node-RED.

For Registration: https://lu.ma/makerchat0x0E

Location : KeyValue Software Systems Pvt Ltd, C113, 1st floor, Building SCK-01 SmartCity, Kakkanad, Kochi, Kerala 682042, India

Date & Time : Saturday 8th , 2:00 PM to 4:00 PM IST

FREE Registration Join and meet like-minded makers and hardware enthusiasts.

#MakerGram #MakerChat #meetup #nodered
1 Reply Last reply
Reply Quote 2
